Flare fittings are essential components in hydraulic and plumbing systems, creating reliable, leak-free connections. Two of the most common types are JIC (Joint Industry Council) and SAE (Society of Automotive Engineers) flare fittings. While they both serve the same basic purpose, they are not interchangeable.
This blog post will delve into the differences between JIC and SAE flare fittings, their sizes, and their best applications, helping you make informed decisions for your projects.
Understanding Flare Fittings
Flare fittings create a seal by using a flared end on a tube that presses against a matching flared surface in the fitting body. The angle of this flare is critical to the sealing process. JIC fittings utilize a 37-degree flare, while SAE fittings use a 45-degree flare. This difference in angle is the primary reason they are incompatible.
Flare fittings are commonly made from materials like steel, stainless steel, brass, and aluminum, each offering different properties in terms of pressure rating, corrosion resistance, and cost.
What Are JIC Flare Fittings?
JIC fittings, also known as 37-degree flare fittings, are widely used in high-pressure hydraulic systems.
➡️ Common Applications:
➡ Hydraulic systems, aerospace, industrial machinery, and other high-pressure environments.
➡️ Benefits:
➡ High-pressure resistance.
➡ The metal-to-metal seal minimizes the need for additional sealants.
➡ Interchangeable with AN (Army-Navy) fittings.
➡️ Limitations:
➡ Not compatible with SAE 45-degree fittings.
➡ Requires precision flaring tools for proper installation.
What Are SAE Flare Fittings?
SAE fittings, or 45-degree flare fittings, are more common in lower to medium-pressure applications.
➡️ Common Applications:
➡ Automotive fuel systems, refrigeration, HVAC, and plumbing.
➡️Benefits:
➡ Widely used in low- to medium-pressure applications.
➡ Relatively easy to install with commonly available tools.
➡ Cost-effective compared to JIC fittings.
➡️Limitations:
➡ Not suitable for very high-pressure applications.
➡ Not interchangeable with JIC fittings.
Key Differences Between JIC and SAE Flare Fittings
|
Feature |
JIC (37°) |
SAE (45°) |
|
Flare Angle |
37° |
45° |
|
Best For |
High-pressure hydraulic systems |
Automotive, HVAC, low-pressure systems |
|
Interchangeability |
Can interchange with AN fittings |
Not interchangeable with JIC |
|
Sealing Method |
Metal-to-metal flare seal |
Metal-to-metal flare seal |
|
Common Materials |
Steel, stainless steel |
Brass, copper, aluminum |
|
Pressure Rating |
Higher pressure tolerance |
Lower pressure tolerance |
How to Identify and Measure Flare Fittings
Identifying and measuring flare fittings correctly is crucial for ensuring compatibility.
1. Determine the flare angle: Use a protractor or flare gauge to measure the angle of the flare.
2. Measure the thread size and pitch: Identify the thread size and the distance between threads (pitch).
3. Check the fitting material and application requirements: Consider the material and intended use of the fitting.
4. Use a standard flare fitting size chart: Consult a size chart for reference.
Choosing the Right Flare Fitting for Your Application
➡️ Use JIC fittings if:
➡ You need high-pressure resistance (e.g., hydraulics, aerospace).
➡ You require a durable, vibration-resistant connection.
➡️ Use SAE fittings if:
➡ You are working on automotive fuel systems, HVAC, or refrigeration.
➡ You need a lower-cost solution for low- to medium-pressure applications.
Common Misconceptions About JIC and SAE Fittings
➡️ “They are interchangeable” → False! The different flare angles make them incompatible.
➡️ “JIC is always better than SAE” → Not necessarily! SAE fittings are often better suited for specific applications like fuel lines and HVAC systems.
➡️ “SAE fittings are outdated” → No! They are still widely used in modern applications.
Final Thought
Choosing between JIC and SAE flare fittings depends on your specific pressure requirements, application type, and compatibility needs. Accurate measurement is essential for ensuring the correct fit.
When in doubt, consult a fittings specialist to avoid costly mistakes and ensure the safety and reliability of your system.
